LiPo Charger 3.7V with DC-DC Boost 4.5-24V – Type C

This module is a small single cell lithium battery charging module which also includes a 1A step-up (boost) converter for powering a large range of applications. The module will charge most types of single cell (3.7) LiPo batteries from either 4 to 8V power supply input, or from a standard 5V USB Type-C port/adapter. A battery charge and standby LED is also included for visual indication.

Besides battery charging capabilities this module also includes an adjustable boost converter which is capable of stepping up the attached battery voltage from 4.5 to 24V with a maximum supply current of 1A.

Quick Spec

• Input Voltage (USB Type-C): 5V
• Input Voltage (IN): 4 – 8V
• Battery Type: LiPo 3.7V
• Default Charging Current: 1000mA
• Output Voltage: 4.5 – 24V
• Max Output Current: 1A
• Dimensions: 33 x 24mm
• Weight: 6g

Board Layout

Shipping List

• 1 x LiPo Charger 3.7V with DC-DC Boost 4.5-24V – Type C
